WMR3-21 is a wall-mounted card reader that is designed to read contactless media (smart cards, key chains, etc.), which are used for controlling access to buildings or their parts.

With the glass controller, WMR3-21 users will appreciate the easy of control using two push buttons, which can be assigned different control functions lighting, shading, scenes, heating, etc.

WMR3-21 reader can be used to control the security system (locking/ unlocking) access system (opening doors, gates, etc.), or appliances (based on assigned rights).

WMR3-21 supports RFID media with a carrier frequency of 13.56 MHz. Supported card types MIFARE Ultralight, DESFire 2K (EV1), DESFire 4K (EV1).

WMR3-21 is also equipped with 8 A relay output with changeover contact AgSnO2, by which controlled devices can be switched directly (or any actuator in the system can be set in software iDM3).

Indication two-color LED in the controller cover can indicate not only the status of the controlled appliance but also the status of any sensor or actuator in the system.

Wall card reader WMR3-21 is compatible with both types of frames LOGUS90 (85.6 x 85.6 or 94 x 94 mm), therefore you can combine them with double and triple frames and classic products of the series.
