RFDA-73M/RGB

The dimmer for LED strips is used for independent control of 3 single-color LED strips or one RGB LED strip.

The expanded selection of control modes enables it to be combined with:

a) detectors, controllers, and system units iNELS RF Control

b) device with output signal 0 (1)–10 V

c) potentiometer.

The unit‘s 3-MODULE design with switchboard mounting enables connection of dimmed load 3x 5 A, which represents:

a) single-color LED strip 7.2 W – 3x 8 m

b) RGB LED strip 14.2 W–10 m.

6 light functions – smooth increase or decrease with time setting 2 s – 30 min.

The dimmer may be controlled by up to 32 channels.

The power supply of the unit is in the range of 12–24 V DC and is indicated by a green LED.

The package includes an internal antenna AN-I, in case of locating the unit in a metal switchboard, you can use the external antenna AN-E for better signal reception

Memory status can be pre-set in the event of a power failure.

Range up to 160 m (in open space), if the signal is insufficient between the controller and unit, use the signal repeater RFRP-20 or protocol component RFIO2 that supports this feature.

Communication frequency with bidirectional protocol RFIO2.
